SPECIFICATIONS

06

06C

06E

06E-1

06C-1

06C-RC

Monocular Head

FiXed 45˚ inclined

*

45˚ inclined, 360˚ Rotatable

*

*

*

*

*

Eyepiece

WF10X

*

*

*

*

*

*

Objective

Achromatic Objective 4X,10X,40X(S)

*

*

*

*

Achromatic Objective 10X,40X(S),100X(S)oil

*

*

Stage

Plain stage with slide clips, stage size: 110X120 mm

*

*

*

*

Double layers mechanical stage 110X125mm, moving in the range of 30X60mm

*

*

Diaphragm

Five-stop dial optical grating

*

*

*

*

Ф2mm- Ф30mm iris diaphragm and filter

*

*

Condenser

Single lens NA0.65

*

*

*

*

Abbe condenser N.A 1.25

*

*

Focusing

Coarse focus adjustment

*

Coaxial coarse & Fine Focus Adjustment

*

*

*

*

Power

Built-in Lamp 110V-220V ,10W-20W

*

*

*

*

Plan-concave Mirror

*

With a Charger and 3 Rechargeable Batteries

*
