SPECIFICATION

701AN

701BN

701AN-M

701BN-M

701AN-T

701BN-T

701DN

Viewing head

Monocular head, Inclined at 45˚, 360˚ Rotatable

*

Sliding binocular head, Inclined at 45˚, 360˚ Rotatable

*

Sliding Trinocular head, Inclined at 30˚, 360˚ Rotatable

*

Articulated Free Binocular Head, Inclined at 30˚, 360˚ Rotatable, Built-in Digital Camera System, Resolution: 1280(H)X1024(V), 1/2 Chip, USB2.0 with Micro-image Process Software

*

Eyepiece

 WF10X, WF16X

*

*

*

*

Objective

Achromatic Objective 4X,10X,40X(S), 100X(S, Oil)

*

*

*

*

Stage

Double Layers Mechinical stage140X155mm

*

*

*

*

Diaphragm

Ф2mm-Ф30mm iris diaphragm and filter

*

*

*

*

Condenser

Abbe NA 1.25 condenser with Iris Diaphragm & Filter

*

*

*

*

Focusing

Coaxial Coarse & Fine Focus Adjustment: 25mm

*

*

*

*

Power

Built-in Adjustable Brightness Halogen lamp 6V/20W

*

*

*

*
