Model |
ZTX-S1 |
ZTX-S2 |
|
Eyepiece |
10X |
|
Zoom objective |
0.7X-4.5X |
1X-4X |
|
Zoom ratio |
1:6.5 |
1:4 |
|
Total Magnification |
7X-45X |
10X-40X |
|
Working distance |
90mm |
90.5mm |
|
Working field of objective |
§¶25.7-§¶4 |
§¶20-§¶5.5 |
|
Working field of image |
§¶18 |
|
The distance between the top of microscope top and CCD image sensor |
17.5 |
|
Power supply |
Electric apparatus has CE approval, Power supply 110V/60Hz or 220V/50Hz |
|
Illumination |
Incident illumination &transmitted illumination |
|
Package |
Each set packed in styrofoam and in an inner box. two sets in one carton |
|
Optional accessories |
VD-TV ,VD-PC ,0.5X Medium Adapter |
Products
Name:ZTX-S SERIES
